Yamaha NMAX 155
Make precious memories with Yamaha Nmax
Yamaha NMAX 155
Fuel efficient, Agile and Stylish
Yamaha NMAX 155
Fuel efficient, Agile and Stylish
Previous slide
Next slide
MODELS
MOTORCYCLES



Enquiry Form
4-STROKE, SOHC, VVA
CYLINDER VOLUME
155 CC
GROUND HEIGHT
124 MM
FUEL CAPACITY
7.1 LITERS
FEATURES
Multifunction Digital Speedometer
The trendy new speedometer design with multiple functions adding to the elegance of the scooter
Blue Core & VVA technology
Blue Core and VVA technology ensure the engine remains fuel efficient while delivering maximum power and torque at every speed
Dual Channel ABS
Dual Channel Anti-Lock Braking System (ABS) provides optimal braking control
Front & Rear Disc Brake
Featuring dual braking system and robust disc grip enhancing driving experience
Large Under seat Storage
Spacious large under seat storage for multiple purposes
Start and Stop System
Improves fuel efficiency by reducing unnecessary fuel consumption when motorcycle is stopped
Traction Control System
Minimizes rear tire slippage during acceleration across all road surfaces
SPECIFICATIONS
YAMAHA NMAX
Engine Type | Liquid cooled 4-stroke, SOHC, VVA |
Number/Position of Cylinders | Single Cylinder |
Cylinder Volume | 155.09cc |
Diameter x Step | 58 mm x 58.7 mm |
Compression Ratio | 11.6 : 1 |
Maximum Power | 11.3kW / 8000 rpm |
Maximum Torque | 13.9 Nm / 6500 rpm |
Starting System | Electric Starter |
Lubrication System | Wet Sump |
Engine Oil Capacity | 0,9 L (Periodical Change) |
Fuel System | Fuel Injection |
Clutch Type | Single Dry Clutch |
Transmission Type | Automatic |
P x L x T | 1935 x 740 x 1160 mm |
Wheelbase | 1340 mm |
Seat Height | 765mm |
Content Weight | 130kg (Standard & Connected Version), 132 kg (Connected/ABS Version) |
Fuel Tank Capacity | 7.1 L |
Ignition System | TCI |
Battery | YTZ6V/YT27V |
Spark Plug Type | NGK/CPR8EA-9 |
